IsoFlex IFV30 HD-16S Flexible Coupling Element – Red (Shore 60)

---

Product Description

The IsoFlex IFV30 HD-16S Flexible Coupling Element (Red – Shore 60) is a high-performance elastomer coupling insert designed to provide vibration isolation, shock absorption, and controlled flexibility in marine driveline and mounting systems.

This flexible element is engineered from IsoFlex’s advanced polymer material, offering superior resistance to fuel, oil, water, and harsh marine environments. The Shore 60 (red) durometer provides a balanced combination of flexibility and load capacity, making it ideal for medium-duty marine applications.

IsoFlex coupling elements are designed to act as a sacrificial and protective component, absorbing driveline stress and misalignment while protecting gearboxes, shafts, and mounts from damage.

---

Key Features

• Genuine IsoFlex flexible coupling element
• Red (Shore 60) durometer – medium stiffness
• Absorbs vibration and drivetrain shock
• Compensates for minor misalignment
• High-performance engineering polymer construction
• Resistant to oil, fuel, water, and harsh environments
• Designed to protect gearbox and driveline components

---

Compatibility

IsoFlex Systems

Compatible with:

• IsoFlex IFV30 coupling assemblies
• HD-16S mount and coupling configurations
• IsoFlex modular mounting and driveline systems

Designed for use with IsoFlex flexible coupling and mount systems

---

Marine Driveline Applications

Commonly used in:

• Inboard marine engines
• Shaft-driven propulsion systems
• Gearbox-to-shaft coupling assemblies
• Engine mount and isolation systems

---

Serial Number Fitment Notice

Fitment depends on:

• Coupling model (IFV30 / HD-16S required)
• Load requirements
• Durometer selection (Shore rating)

Always confirm compatibility with your IsoFlex system and application requirements before ordering.

---

Specifications

• Part Type: Flexible coupling element
• Model: IFV30 HD-16S
• Durometer: Shore 60 (Red)
• Material: Engineering-grade polymer
• Function: Vibration isolation and shock absorption

---

Durometer Guide (Important)

• Red (Shore 60): Medium flexibility – general marine use
• Softer cores: More vibration isolation, less load capacity
• Harder cores: More load capacity, less vibration absorption

Correct durometer selection is critical for performance

---

What’s Included

• (1) IsoFlex flexible coupling element (Red – Shore 60)

---

When This Part Needs Replacement

Replace the element if you notice:

• Cracking or deformation
• Excessive vibration or noise
• Loss of flexibility
• Driveline misalignment issues

---

Installation Notes

• Install as part of complete IsoFlex coupling system
• Ensure correct durometer for application
• Inspect bushings and hardware during installation
• Torque all fasteners evenly
• Re-check alignment after installation

---

Alternate / Superseded Part Numbers

OEM Cross References

• IsoFlex: IFV30 HD-16S (Red / Shore 60)

---

Related Components

• IsoFlex Couplings (e.g., IFC series)
• IsoFlex T-Bushing Kits (e.g., TBUSHKIT3/4)

---

Shipping

Shipping: Ships same or next day for fast Canada wide shipping.

---

Parts Desk Insight

The color matters here—red (Shore 60) is the most common “balanced” option. Too soft and you get excess movement, too hard and you lose vibration isolation
