Description

The Lowrance HOOK Reveal 7 TripleShot with C-MAP Discover is a 7-inch fishfinder/chartplotter designed to make fish easier to find with FishReveal, Autotuning Sonar, SideScan, DownScan Imaging, and wide-angle High CHIRP sonar from the included TripleShot transducer. It also includes C-MAP Discover OnBoard inland and coastal mapping, giving anglers detailed chart coverage with 1-foot contours on thousands of U.S. and Canadian lakes, plus Genesis Live real-time mapping for creating custom contour maps while on the water.

Key Features

• 7-inch HOOK Reveal fishfinder/chartplotter
• Included TripleShot Skimmer transducer
• High CHIRP sonar, SideScan, and DownScan Imaging
• FishReveal combines CHIRP sonar targets with DownScan structure detail
• Autotuning Sonar automatically adjusts sonar settings as conditions change
• SolarMAX display for bright, sunlight-readable viewing
• Display resolution: 800 x 480
• Screen brightness: over 1000 nits
• Includes C-MAP Discover OnBoard inland and coastal charts
• Genesis Live real-time mapping
• microSD card slot, up to 32 GB
• Mapping support includes C-MAP, C-MAP Genesis, Genesis Live, Navionics, and more
• Supply voltage: 12V DC, 10.8–17V DC
• Recommended fuse: 5A
• Waterproof rating: IPX7 with card door closed
• Dimensions: 9.31 in. W x 6.46 in. H x 4.42 in. D
• Weight: 1.25 lb / 0.57 kg

Application Compatibility

This unit is suited for freshwater and coastal anglers who want a compact 7-inch display with sonar, mapping, and side-imaging capability in one package. It is a good fit for fishing boats, aluminum boats, small cruisers, centre consoles, lake boats, and other helm or dash installations where a 7-inch fishfinder/chartplotter is the right size.

Fitment Notice

This is a marine electronics product, not an engine-specific part. Before ordering, confirm available dash or bracket mounting space, transducer mounting location, 12V power supply, fuse protection, cable routing, and chart coverage needs. This model includes the TripleShot transducer and C-MAP Discover OnBoard card; GPS-only “X” models do not support the same mapping features.

When This Part Needs Replacement

Replace or upgrade to this unit when an older fishfinder lacks side imaging, modern mapping, sunlight-readable display quality, or reliable sonar performance. It is also a strong upgrade when moving from basic depth-only electronics to a fishfinder/chartplotter with CHIRP, SideScan, DownScan, FishReveal, and live contour mapping.

Installation Notes

The package includes the HOOK² / Reveal power cable, fuse and fuse holder, 7-inch gimbal bracket and knobs, TripleShot Skimmer transducer, and corner clips. The display can be installed using a gimbal bracket or front-dash/flush-mount setup. Mount the transducer in clean water flow, route the cable away from sharp edges and electrical noise where practical, and use the recommended fuse protection during installation.

Alternate/Superseded Part Numbers

• 000-15853-001
• 149-00015853001
• Lowrance HOOK Reveal 7 TripleShot C-MAP Discover
• HOOK Reveal 7 TripleShot with C-MAP Discover OnBoard Card
• HOOK Reveal 7 TripleShot with C-MAP Contour+ / Discover mapping reference

Parts Desk Insight

The TripleShot version is the one to choose when side-to-side structure viewing matters. It gives anglers CHIRP, DownScan, and SideScan from one transducer, while the included C-MAP mapping and Genesis Live help make the unit more useful for finding ledges, drop-offs, weedlines, and bottom changes.
