Description

Ronstan Carbon Fibre C-Cleat / Cam Cleat, Medium

RF5410, RF5410B, RF5410G, RF5410R, RF5010, RF5410Y

• Design, materials selection and advanced manufacturing methods combine to deliver superior strength and holding power, light weight and corrosion resistance
• Cam profile and multi-coil spring minimise line entry and release effort
• Carbon fibre composite cam material provides maximum resistance to heat and abrasion
• Unique self-cleaning, self-lubricating slotted bearings ensure consistent high performance even when subjected to high static loads

Applications

• Range of cleats for all requirements including control lines, jib sheet and mainsheet cleating

Materials

• Carbon fibre composite cams
• Long strand glass fibre reinforced polymer base
• PTFE impregnated Acetal slotted bearing
• Stainless steel multi-coil spring

Specifications

• Rope Ø: 3 – 12 mm
• Height: 26.0 mm
• Width: 31.0 mm
• Length: 66.0 mm
• Fastener Ø: M5 mm
• Fastener Hole Centres: 38.0 mm
• MWL: 125 kg
• BL: 250 kg
• Weight: 50 g
