Description
This antenna covers digital, analog and PCS cell phone bands in an eight-foot radome that coordinates with other Shakespeare Galaxy antennas. Electrical connections are hand soldered for reliability. A brass choking sleeve eliminates pattern distortion due to cable radiation. Use one of Shakespeare’s CPA Series adapters to connect your portable cell phone.
Shakespeare Galaxy 5237-XT
8′ Dual Band Cellular 3dB Gain
800/900 MHz and 1900 MHz Cellular
This antenna covers digital, analog and PCS cell phone bands in an eight-foot radome that coordinates with other Shakespeare Galaxy antennas. Electrical connections are hand soldered for reliability. A brass choking sleeve eliminates pattern distortion due to cable radiation. Use one of Shakespeares CPA Series adapters (sold separately) to connect your portable cell phone.
- Brass and copper elements to maximize range
- Stainless steel ferrule w/ standard 1″-14 thread
- Includes 25′ of Shakespeare exclusive Lo-Max® low-loss cable and a “TNC” connector
- Suggested mount: Shakespeare Style 4187 Ratchet Mount
- Shakespeare Limited Warranty: 5 years
All Galaxy® Dual Band Cellular antennas feature Shakespeares exclusive Lo-Max® Cable. This flexible, UV stable coax provides low-loss characteristics near that of larger RG-8 A/U and RG-213, but without the extra bulk and rigidity.
Technical Specifications:
| Frequency: | Dual Band 800-890 MHz and 1800-1900 MHz |
| Bandwidth: | 96 MHz within 2.0:1 VSWR (analog band) |
| 140 MHz within 2.0:1 VSWR at (digital band) | |
| SWR: | nominally less than 1.5:1 at 852.65 MHz; |
| nominally less than 1.5:1 at 1918.7 MHz | |
| Gain: | 3 dB |
| Height (feet): | 8 |
SKU: NVN-14044
MPN: 5237-XT
UPC: 719441900229
