Description

The Volvo Penta Seawater Pump 3838288 is a genuine OEM raw-water cooling pump used on Volvo Penta D5 and D7 marine diesel applications. It circulates seawater through the engine cooling circuit to help maintain correct operating temperature under load.

Key Features

• Genuine Volvo Penta seawater pump
• Part number: 3838288
• Product type: raw-water / seawater pump assembly
• Diagram reference: 1
• Common pump manufacturer reference: Johnson 10-24580-01
• Aftermarket replacement reference: JMP JPR-VP0050D
• Used on Volvo Penta D5A and D7A/D7C engine families
• Related wear kit: 21951394
• Related shaft kit: 21951459
• Related impeller kit references: 3841697, 21422647, 21951356
• Related impeller reference: 21422632
• Related screw kit: 21951336
• Related gasket reference: 808275

Engine Compatibility

Commonly associated with Volvo Penta diesel engine models including:

• D5A-A T
• D5A-A TA
• D5A-B TA
• D5A-T
• D5A-TA
• D7A-A T
• D7A-A TA
• D7A-B TA
• D7A-T
• D7A-TA
• D7C-A TA
• D7C-B TA
• D7C-TA

Serial Number Fitment Notice

Confirm fitment by engine model, serial number, pump body, port orientation, and cooling-system diagram before ordering. D5/D7 seawater pumps can share similar layouts, but internal service parts, shaft kits, and impeller references can vary by pump version.

When This Part Needs Replacement

Replace the seawater pump if raw-water flow is weak, the engine overheats, the pump leaks, the shaft has play, bearings are noisy, the housing is cracked or corroded, seals fail, or the pump body is worn from impeller or cam damage.

Installation Notes

Install according to the Volvo Penta service procedure for the exact D5/D7 engine. Inspect the impeller, cam, cap, gasket, wear washer, shaft kit, seals, bearings, lock ring, and cover screws during service. After installation, verify strong raw-water discharge and check all hose connections for leaks.

Alternate/Superseded Part Numbers

Related references include:

• 3838288
• Johnson 10-24580-01
• JMP JPR-VP0050D
• REC3838288
• JPR-VP0050D
• 3841697 — earlier impeller kit reference
• 21422647 — later impeller kit reference
• 21951356 — current impeller kit reference

Parts Desk Insight

This pump has solid match points: 3838288, Volvo Penta D5/D7 diesel applications, and Johnson pump reference 10-24580-01. Before ordering, compare the old pump’s body, port orientation, and serial-number diagram because raw-water pumps that look close can differ internally.

Special Order: This product is not currently in store inventory but may be available from the Manufacturer. Special Orders may take up to 2 weeks to arrive. Call the parts desk before ordering if you need a closer estimate on delivery time.
